Sony PXW-Z280 4K 3-CMOS 1/2″ Sensor XDCAM Camcorder

Sony PXW-Z280 4K 3-CMOS 1/2″ Sensor XDCAM Camcorder

World-leading handheld 4K HDR performance
An all-new 4K 3CMOS 1/2-type sensor with a deep depth of field and class-leading performance provides the pinnacle of 4K HDR performance in your hand. Face Detection AF keeps your subject in focus, while HLG and S-Log3 provide stunning HDR to suit any workflow.

Revolutionary networking capabilities
Deliver your content faster wherever you are. PXW-Z280 is the world’s first camcorder with Dual Link Cellular capability for double the uplink performance and reliability.

The complete package for professionals
Unpack and shoot from day one. Advanced XAVC-Intra and XAVC-Long for 4K QFHD and HD, plus MPEG HD422, MPEG HD and DVCAM to support any workflow. Familiar Sony control layout and operation minimise training requirements.

World’s first 1/2-type 3CMOS Sensor for broadcast 4K
The Z280’s all-new Exmor R™ imager is custom-designed for broadcast 4K acquisition. Its three 1/2-type Exmor R™ CMOS deliver a deep depth of field with superb image quality. Red, blue, and green light are independently captured by separate image sensors, contributing to high resolution, high sensitivity of F12 (59.94p) and wide dynamic range. An advanced LSI (featuring intelligent noise reduction and enhanced detail reproduction) delivers remarkably lifelike 4K 4:2:2 10-bit images. Even if you’re delivering in HD, your recordings will capture detail and image texture that HD sensors simply cannot see.

17x professional HD zoom lens with three independent rings with end-stop and large focal length
The PXW-Z280 is equipped with a 17x professional zoom lens able to zoom from 30.3mm to 515mm (35mm equivalent). The 1/2-inch type lens has three independent control rings with end-stop, which allows manual control of focus, zoom and iris, making for better and faster adjustment.

The image can be enlarged in HD mode up to 34x zoom equivalent while maintaining Full HD resolution thanks to digital extender.

Spectacular HDR performance
Demand for HDR content is increasing and Z280 offers you a choice of two powerful workflows.

• S-Log3 is the proven choice for premium applications where you wish to capture as much data as possible for the ultimate flexibility in grading
• Instant HDR Workflow is all about speed. Shoot, edit and view content in Hybrid Log-Gamma (HLG) to deliver content quickly without compromising on imaging expression and quality of content

HDR / SDR dual production support
When shooting HDR content, the Z280’s EVF is easily switched between HDR and SDR emulation modes. In addition, if you adjust the brightness of the image when in SDR emulation, the SDR gain dB is recorded into metadata so it can be used in post-production for the SDR content. Together these changes make it easier to shoot in HDR while also achieving a quick turnaround for SDR content.

Amazingly fast precision auto focus
The PXW-Z280 features newly developed Face detection AF. You can choose between Face Priority AF and Face Only AF. Simply keep the person in frame and and however you move to obtain a better angle, you can be confident the PXW-Z280 will keep your subject in pin-sharp focus.

Built-in electronic Variable ND Filters
Sony’s ground-breaking integration of electronic variable ND Filters into the body of a camcorder enables fast, agile shooting. Moving from shadowy interiors to bright sun-lit exteriors is no problem with PXW-Z280. Unlike conventional optical ND filters, the electronic ND filter on the PXW-Z280 can be controlled from 1/4ND to 1/128ND linearly while ND Filters can be set to fully auto. You can even manually adjust Depth of Field using the iris lens ring, while relying on the PXW-Z280 to maintain constant exposure without changing gain nor shutter speed.

Stream directly to major online platforms
Live streaming instantly connects you with your audience, wherever you are. From breaking news and live events to interviews and seminars – capture high-quality images and share them in real time on major online video platforms such as YouTube Live, Facebook Live, Mudu.tv and more. Set up your own streaming channel with your smartphone or tablet, connect via Wi-Fi – and you’re ready to go. You can even import streaming account details from your PC or Mac via SD card using our StreamingSettingTransfer app.

12G-SDI accelerated workflow
Revolutionise your workflow with 12Gbps content transfer – four times the bandwidth of 3G-SDI over a single cable and ideal for working with highest quality 4K content or speeding through HD content. Sony is the first broadcast manufacturer to build 12G-SDI into a compact handheld camcorder. Once you’ve tried it, you won’t want to use anything else.

Accurate OLED viewfinder
An expansive 0.5-inch high quality OLED viewfinder is perfectly offset for right-eye or left-eye viewing. OLED’s superb accuracy, high contrast and high resolution (2.36M dot) enables precise manual focus and eliminates any colour-breaking phenomenon.

Dual Multi-Interface (MI) Shoe
MI Shoe provides power, signal connections and coordinated on/off switching to compatible Sony accessories. For example, you can connect and control Sony wireless microphone systems such as the UWP-D11 or UWP-D12 or attach the HVL-LBPC light *Connectors at front and back of camcorder maximise operational flexibility.

Dual XLR and 4 Channel Audio
The PXW-Z280 offers superior professional audio capabilities with independent volume dials enabling precision control of external audio inputs, including an MI-shoe attached microphone.

Dual SxS media slots
The camcorder is equipped with two SxS memory card slots, which can record in Simul, Relay or Back up mode. Simul mode permits simultaneous recording to two memory cards, including simultaneous recordings of MPEG HD exFAT and UDF recordings, ideal for archival purposes. Relay mode automatically switches recording from the first to the second memory card when the first is full to extend recording times. In Back up mode, users can set up the two Start/Stop buttons on the PXW-Z280, one on the grip and one on the camcorder body, to independently start and stop recording on different memory cards while recording in Simul mode.

Specifications

• General
  Important Note
  PXW-Z280 is available from Sony as two SKUs. PXW-Z280V supports both 5Ghz and 2.4Ghz Wi-Fi. PXW-Z280T supports 2.4GHz Wi-Fi. Availability is determined by country/regional regulations.
  Mass
  Approx 2.6 kg (body)
  Approx. 5 lb 11.7 oz (body)
  Approx. 3.0 kg (with lens hood, eyecup, BP-U35 battery, a SxS memory card)
  Approx. 6 lb 9.8 oz (with lens hood, eyecup, BP-U35 battery, a SxS memory card)
  Dimensions (W x H x D)
  178.4 × 202.0 × 426.3 mm (With the accessories (lens hood, eyecup), excluding the grip belt and including the projecting parts)
  7 1/8 x 8 x 16 7/8 inches (With the accessories (lens hood, eyecup), excluding the grip belt and including the projecting parts)
  Power Requirements
  DC In: 12V
  Battery: 14.4 V
  Please use genuine Sony batteries to ensure correct and safe operation*2
  Power Consumption
  Approx. 24W
  (while recording with LCD Off, EVF On when the external device connector is not used.)
  Approx. 36W
  (while recording with LCD On, EVF On when the external device connector is used.)
  Operating Temperature0°C to 40°C
  32°F to 104°F
  Storage Temperature-20°C to +60°C
  -4°F to +140°F
  Battery Operating Time
  Approx. 1 hours, 20 minutes with BP-U35 battery
  (while recording with LCD Off, EVF On when the external device connector is not used.)
  Approx. 1 hours, 5 minutes with BP-U30 battery
  (while recording with LCD Off, EVF On when the external device connector is not used.)
  Approx. 2 hours, 10 minutes with BP-U60 battery
  (while recording with LCD Off, EVF On when the external device connector is not used.)
  Approx. 3 hours, 15 minutes with BP-U90 battery
  (while recording with LCD Off, EVF On when the external device connector is not used.)
  Recording Format (Video)
  XAVC-I QFHD mode:
  MPEG-4 AVC/H.264, VBR, Max.600 Mbps
  XAVC-I HD mode:
  MPEG-4 AVC/H.264, CBG, Max.222 Mbps
  XAVC-L QFHD mode:
  VBR, maximum bit rate 150Mbps, MPEG-4 H.264/AVC
  XAVC-L HD 50 mode:
  VBR, maximum bit rate 50Mbps, MPEG-4 H.264/AVC
  AVC-L HD 35 mode:
  VBR, maximum bit rate 35Mbps, MPEG-4 H.264/AVC
  XAVC-L HD 25 mode:
  VBR, maximum bit rate 25Mbps, MPEG-4 H.264/AVC
  MPEG HD422 mode:
  CBR, maximum bit rate 50Mbps, MPEG-2 422P@HL
  MPEG HD420 HQ mode:
  VBR, maximum bit rate 35Mbps, MPEG-2 MP@HL
  DVCAM mode:
  CBR, 25Mbps, DVCAM
  Recording Format (Audio)
  XAVC-I mode:
  LPCM 24-bit, 48kHz, 4 channels:
  XAVC-L mode:
  LPCM 24-bit, 48kHz, 4 channels:
  MPEG HD422 mode:
  LPCM 24-bit, 48kHz, 4 channels:
  MPEG HD420 HQ mode:
  LPCM 16-bit, 48kHz, 4 channels:
  DVCAM mode:
  LPCM 16-bit, 48kHz, 4 channels
  Recording Frame Rate
  XAVC-I QFHD mode:
  3840×2160/59,94p, 50p, 29.97p, 23.98p, 25p
  XAVC-I HD mode:
  1920×1080/59,94p, 59.94i, 50p, 50i, 29.97P, 23.98P, 25P 1280×720/59.94P, 50P
  XAVC-L QFHD 150 mode:
  3840×2160/59.94P, 50P, 29.97P, 23.98P, 25P
  XAVC-L HD 50 mode:
  1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P 1280×720/59.94P, 50P
  XAVC-L HD 35 mode:
  1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P
  Recording Frame Rate – ContinuedXAVC-L HD 25 mode:
  1920×1080/59.94i, 50i
  MPEG HD422 mode:
  1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P
  1280×720/59.94P, 50P, 29.97P, 23.98P, 25P
  MPEG HD420 HQ mode:
  1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P
  1440×1080/59.94i, 50i
  1280×720/59.94P,50P
  DVCAM mode:
  720×480/59.94i, 29.97PsF
  720×576/50i, 25PsF
  Recording/Playback Time
  XAVC-I QFHD mode
  When using SBP-128B(128GB):
  Approx. 22 minutes
  XAVC-I HD mode
  When using SBP-128B(128GB):
  Approx. 57 minutes
  XAVC-L QFHD 150 mode
  When using SBP-128B(128GB):
  Approx. 86 minutes
  XAVC-L HD 50 mode
  When using SBP-128B(128GB):
  Approx. 230 minutes
  XAVC-L HD 35 mode
  When using SBP-128B(128GB):
  Approx. 310 minutes
  Recording/Playback Time – ContinuedXAVC-L 25 mode
  When using SBP-128B(128GB):
  Approx. 420 minutes
  MPEG HD422 mode
  When using SBP-128B(128GB):
  Approx. 215 minutes
  MPEG HD420 HQ mode
  When using SBP-128B(128GB):
  Approx. 330 minutes
  When using SBP-128B(128GB):
  Approx. 405 minutes
  Recording Format (Proxy Audio)
  XAVC Proxy: AAC-LC, 128 kbps, 2 channels
  Recording Format (Proxy Video)
  XAVC Proxy: AVC/H.264 Main Profile 4:2:0 Long GOP, VBR
  1920×1080, 9Mbps
  1280×720, 9Mbps
  1280×720, 6Mbps
  640×360, 3Mbps
  480×270, 1Mbps
  480×270, 0.5Mbps
• Lens
  Lens Mount
  Fixed
  Zoom Ratio
  17x (optical), servo/manual
  Focal Length
  f = 5.6 – 95.2 mm
  (35mm equivalent: 30.3 – 515 mm)
  Iris
  F1.9 – F16 and close
  auto/manual selectable
  Focus
  800 mm to ∞ (Macro Off),
  50 mm to ∞ (Macro On, Wide),
  800 mm to ∞ (Macro On, Tele)
  AF/MF/Full MF selectable
  Image Stabilizer
  On/Off selectable, shift lens
  Filter Diameter
  φ77 mm, pitch 0.75mm
• Camera Section
  Imaging Device (Type)
  1/2 type back-illuminated Exmor R 3CMOS sensor
  Effective Picture Elements
  3840 (H) x 2160 (V)
  Optical System
  F1.6 prism system
  Built-in Optical Filters
  ND filters
  OFF: CLEAR
  1: 1/4ND
  2: 1/16ND
  3: 1/64ND
  Linear variable ND (Approx. 1/4ND to 1/128ND)
  Sensitivity (2000 lx, 89.9% reflectance)
  F12 (typical, 1920 x 1080/59.94p mode)
  F13 (typical, 1920 x 1080/50p mode)
  F12 (typical, 3840 x 2160/59.94p, High Sensitivity Mode)
  F13 (typical, 3840 x 2160/50p, High Sensitivity Mode)
  Minimum Illumination
  0.0013lx (typical)
  (1920 x 1080/59.94i mode, F1.9, +42 dB gain, High Sensitivity Mode, with 64 frame accumulation)
  S/N Ratio63 dB (Y) (typical)
  Horizontal Resolution
  2,000 TV lines or more (3840 x 2160p mode)
  1,000 TV lines or more (1920 x 1080p mode)
  Shutter Speed
  1/24 sec to 1/8,000 sec
  Slow Shutter (SLS)
  2, 3, 4, 5, 6, 7, 8, 16, 32, and 64-frame accumulation
  Slow and Quick Motion Function
  2160P: 1-60 fps
  1080P: 1-60 fps
  720P: 1-60 fps
  1080P: 1-30 fps
  720P: 1-60 fps
  1080P: 1-30 fps
  720P: 1-60 fps
  White Balance
  Preset (3200K), Memory A, Memory B/ATW
  Gain
  -3, 0, 3, 6, 9, 12, 15, 18 dB, 42dB(Turbo Gain ON), AGC
  Gamma Curve
  Selectable
• Streaming
  Protocol *3
  AVC / RTMP / RTMPS
  1920×1080 at 9Mbps
  1920×1080 at 6Mbps
  1280×720 at 3Mbps
  640×340 at 1Mbps
• Input/Output
  Audio Input
  XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable
  LINE：+4, 0, -3dBu/10kΩ
  MIC：-80dBu to -30dBu /3kΩ
  (0 dBu=0.775 Vrms)
  Video Output
  BNC (x1), HD-Y/ HD-SYNC/Composite
  1.0Vp-p, 75Ω
  (switchable to Genlock in)
  Audio Output
  Integrated into Multi/Micro USB jack(x1)
  SDI OutputBNC (x1), 12G/3G/HD/SD selectable
  Timecode Input
  BNC (x1) (switchable to TC out)
  0.5V-1.8Vp-p, 3.3kΩ
  Timecode Output
  BNC (x1) (switchable to TC in)
  1.0Vp-p, 75Ω
  Genlock Input
  BNC (x1) (switchable to Video out) 1.0 Vp-p, 75Ω
  USB
  USB device, Multi/Micro USB jack (x1)
  Host:USB 3.0/2.0 type A(x1)
  USB 2.0 type A(x1)
  Headphone Output
  Stereo mini jack (x1)
  -16dBu 16Ω
  Speaker Output
  Monaural
  Output: 500mW
  DC Input
  DC jack (x1)
  Remote
  Stereo mini-minijack (Φ2.5 mm)
  HDMI Output
  Type A (x1)
  Wired LAN
  RJ-45 (x1), 1000BASE-T, 100BASE-T, 10BASE-T
• Monitoring
  Viewfinder
  1.3 cm (0.5 type)
  Approx 2.36M dots
  LCD
  8.8cm (3.5 type)
  Approx. 1.56M dots
• Built-in Microphone
  Built-in Microphone
  Omni-directional stereo electret condenser microphone
• Media
  TypeExpress
  Card/34 slot (x2)
• Wi-Fi/NFC
  Supported Format
  IEEE 802.11 a/b/g/n/ac
  Frequency Band
  2.4 GHz bandwidth
  5.2/5.3/5.6 GHz bandwidth*1
  Security
  WEP/WPA-PSK/WPA2-PSK
  NFC
  NFC Forum Type 3 Tag compliant
• Supplied Accessories
  Lens hood (1)
  Pre-installed to the Camcorder EVF eyecup (1)
  Battery pack BP-U30 or U35 (1)
  AC Adapter/charger BC-U1A (1)
  Power Code (1)
  USB cable (1)
  Shoulder strap (1)
  Warranty Booklet (1)
  “Before Using this Unit” (1)
  CDROM “Operating instructions” (1)
