Blackmagic Design Video Assist 3G-SDI/HDMI 5″ Monitor

Blackmagic Design Video Assist 3G-SDI/HDMI 5″ Monitor

Blackmagic Video Assist 5” 3G is a portable monitor, a professional recorder, a portable scope and a fantastic camera viewfinder solution! You can also add better quality record codecs and a larger monitor to any SDI or HDMI camera! The new design has innovations such as 4 built in scopes, enhanced focus assist features, a tally indicator and built in 3D LUTs. The Video Assist 5” 3G support formats up to 1080p60 and the new design also has L-Series batteries for longer life. Blackmagic Video Assist 5” 3G really is 4 products in one!

Specifications

• Connections
  SDI Video Inputs
  1 x Micro BNC
  SDI Video Outputs
  1 x Micro BNC
  SDI Rates
  270Mb, 1.5G, 3G
  HDMI Video Inputs
  1
  HDMI Video Outputs
  1
  Analog Audio Inputs
  None, embedded audio only.
  Analog Audio Outputs
  1 x 3.5mm headphone jack.
  Built in Speaker
  Mono
  Screen Dimensions
  5 inch 1920 x 1080.
  Screen Brightness
  300nits
  SDI Audio Inputs
  16 channels embedded via SDI
  SDI Audio Outputs
  16 channels embedded via SDI
  HDMI Audio Inputs
  8 channels embedded via HDMI
  HDMI Audio Outputs
  8 channels embedded via HDMI
  Remote Control
  None
  SD Interface
  1 x UHS-I SD slot.
  Storage Type
  SDXC UHS-I and SDHC UHS-I SD cards.
  Supports DS, HS, SDR12, SDR25, DDR50, SDR50 and SDR104 SD cards.
  Computer Interface
  1 x USB Type‑C for webcam out, initial setup, software updates and Video Assist Utility software control.
• SDI Video Standards
  SD Video Standards
  525i59.94 NTSC, 625i50 PAL
  HD Video Standards
  720p50, 720p59.94, 720p60
  1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
  1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
  1080i50, 1080i59.94, 1080i60
  2K Video Standards
  2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI
  2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI
  SDI Compliance
  SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 425M
  SDI Metadata Support
  HD RP188
  Audio Sampling
  Television standard sample rate of 48 kHz and 24-bit.
  Video Sampling
  4:2:2 YUV
  Color Precision
  10-bit
  Color Space
  REC 601, REC 709
  Multiple Rate Support
  SDI and HDMI switches between 270 Mb/s, 1.5 Gb/s and 3 Gb/s.
• HDMI Video Standards
  SD Video Standards
  525i59.94 NTSC, 625i50 PAL
  HD Video Standards
  720p50, 720p59.94, 720p60
  1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
  1080i50, 1080i59.94, 1080i60
  HDMI Color Precision
  10-bit
  Copy Protection
  HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
• Media
  Media
  1 x UHS-I SD for HD recording.
  Media Type
  SDXC UHS-I and SDHC UHS-I SD cards.
• Supported Codecs
  ProRes 422 HQ, ProRes 422, ProRes 422 LT, ProRes 422 Proxy, DNxHD 220x, DNxHD 145, DNxHD 45, DNxHD 220x MXF, DNxHD 145 MXF, DNxHD 45 MXF.
• Control
  Recorder Control
  Integrated capacitive touchscreen LCD with Blackmagic OS onscreen controls for settings and navigating menus.
  External Control
  SDI and HDMI start/stop, timecode run.
• Software
  Software Included
  Blackmagic OS
• Scopes
  Scopes
  Waveform, RGB Parade, Vector, Histogram.
  Viewing Modes
  Scopes with picture in picture or picture overlay and opacity control.
• Operating Systems
  Mac 10.14 Mojave,
  Mac 10.15 Catalina or later.
  Windows 8.1 and 10.
• Power Requirements
  Power Supply
  1 x External 12V power supply.
  Compatible with Sony NP-F style batteries.
  (batteries not included)
• Environmental Specifications
  Operating Temperature
  0° to 40° C (32° to 104° F)
  Storage Temperature
  -20° to 45° C (-4° to 113° F)
  Relative Humidity
  0% to 90% non-condensing
• What’s Included
  Blackmagic Video Assist 5” 3G
  Universal power supply with international adapters
