Save 9%

Hollyland Cosmo 2000 HDMI/SDI Wireless Video Transmission System

Make an Inquiry

324,500 295,000

  • HDMI/SDI Input, SDI Loop, 3.5mm Audio
  • HDMI/Dual SDI Outputs
  • 2000′ 1080p60 Transmission, <1ms Latency
  • 5.1-5.9 GHz Frequency Band
  • ALEXA Mini Playback without Waiting
  • Encrypted to Prevent Video Leakage
  • OLED Screen; Smart Cooling Fan
  • Transmitter: 4-Pin LEMO Power Connector
  • Receiver: V-Mount Plate & 4-Pin LEMO
  • D-Tap to LEMO Cables Included

Only 1 left in stock

SKU: 23381 Category:

Description

Hollyland Cosmo 2000 HDMI/SDI Wireless Video Transmission System

The Hollyland Cosmo 2000 allows you to transmit an HDMI/SDI signal up to 2000′ to an HDMI or dual SDI outputs. The transmitter/receiver set supports up to 1080p60 signals with a latency of <1 ms. The transmitter also offers an SDI loop-through output and 3.5mm stereo audio input. The system operates on the 5.1 to 5.9 GHz frequency band and is encrypted to prevent video leakage—only the matched receiver shows clear images; unmatched receivers are unable to, even when on the same frequency. One of the outstanding features of this Cosmo 2000 is a built-in software optimization for use with the ARRI ALEXA Mini. The Cosmo 2000 was designed to successfully handle playback on the ALEXA Mini without waiting. Other features include an OLED screen and a smart cooling fan that automatically kicks in whenever the temperature reaches extreme highs.

The transmitter is designed to be powered via its 4-pin LEMO connector only, and the receiver features a V-mount battery plate and a 4-pin LEMO connector. Two D-Tap to LEMO cables are included to provide the flexibility to power both units via a cable connection to compatible batteries. The transmitter uses two antennas and the receiver five antennas. All seven plus a spare are included, and two mushroom antennas are also supplied as replacements for the transmitter antennas.

Tags: Hollyland Cosmo 2000 HDMI/SDI Wireless Video Transmission System India, Hollyland Cosmo HDMI/SDI Wireless Video Transmission System, Hollyland Cosmo Wireless Video Transmission System, Hollyland Wireless Video Transmission System, Hollyland Cosmo 2000, Hollyland Cosmo 2000 Price, Hollyland Cosmo 2000 Suite

Spacification

Transmitter
Transmission Range 2000′ / 610 m line-of-sight
Latency <1 ms
Connections 1 x HDMI type A input
1 x 3G/HD/SD-SDI input
1 x 3G/HD/SD-SDI loop out
Input Resolution 1080p: 60/59.94/50/30/29.94/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
480p: 60
576p: 503G/HD/SD-SDI auto-selected, SMPTE-259/274/292/296/372/424/425
Supported Audio 1 x 3.5 mm stereo input
Embedded 2-channel 24-bit/48 kHz
Frequency 5.1-5.9 GHz
Antenna Support 2 x RP-SMA male ports
Modulation OFDM 16-QAM
Transmission Power 18 dBm max
Bandwidth 40 MHz
Encryption AES-128 encryption
Display OLED
Firmware Upgradable Mini USB port
Battery Plate No battery plate support; 4-pin LEMO power only
Power Input Connection 4-pin LEMO female
Power Input 7-36 VDC
Power Consumption <9 W
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature Not specified by manufacturer
Dimensions 4.6 x 2.7 x 1″ / 11.6 x 6.8 x 2.5 cm (not including antennas)
Weight 11 oz / 315 g
Receiver
Transmission Range 2000′ / 610 m line-of-sight
Latency <1 ms
Output 1 x HDMI type A output
2 x 3G/HD/SD-SDI
Output Resolution 1080p: 60/59.94/50/30/29.94/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
480p: 60
576p: 503G/HD/SD-SDI auto-selected, SMPTE-259/274/292/296/372/424/425
Supported Audio Embedded 2-channel 24-bit/48 kHz
Frequency 5.1-5.9 GHz
Antenna 5 x RP-SMA male ports
Modulation OFDM 16-QAM
Receiver Sensitivity -75 dBm
Bandwidth 40 MHz
Encryption AES-128 encryption
Display OLED
Firmware Upgradable Mini USB port
Battery Plate V-mount
Power Input Connection 4-pin LEMO female
Power Input 7-36 VDC
Power Consumption <8 W
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature Not specified by manufacturer
Dimensions 6.2 x 4 x 1″ / 15.8 x 10.2 x 2.5 cm
Weight 18.3 oz / 520 g
